型号 | 吸入值 | 吐出值 | |||||
额定 | 值 | ||||||
风量 m3/min | 静压 Kpa | 静压 Kpa | 功率 kw | 静压 Kpa | 功率 kw | 风量 m3/min | |
VB-001-E | 0.3 | 2.7 | 4.6 | 0.007 | 4.9 | 0.008 | 0.65 |
VB-002-E | 0.5 | 3.6 | 6.0 | 0.012 | 6.4 | 0.012 | 1.1 |
VB-003-E | 0.8 | 3.4 | 6.7 | 0.017 | 7.1 | 0.18 | 1.4 |
VB-004-E2 | 0.9 | 4.4 | 9.2 | 0.33 | 10.2 | 0.37 | 1.7 |
VB-007-E2 | 1.4 | 5.9 | 10.8 | 0.59 | 12.3 | 0.65 | 2.6 |
VB-020-E2 | 2.0 | 8.8 | 15.2 | 1.3 | 18.6 | 1.7 | 4.0 |
VB-030-E2 | 2.5 | 10.8 | 17.2 | 1.8 | 19.4 | 2.0 | 5.0 |
VB-040-E2 | 3.0 | 11.8 | 16.2 | 2.1 | 18 | 2.4 | 6.7 |
VB-060-E2 | 4.0 | 13.2 | 19.6 | 4.0 | 24 | 5.0 | 9.0 |
VB-080-E2 | 6.5 | 14.7 | 21.1 | 5.7 | 27.4 | 7.2 | 11 |
VB-110-E2 | 8.0 | 16.7 | 25.5 | 8.8 | 33.3 | 11.6 | 16 |
