技术参数Specificati*** | Units | VMC650 |
工作台尺寸Table size | mm | 800x400 |
X轴行程X axis tr***el | mm | 650 |
Y轴行程Y axis tr***el | mm | 400 |
Z轴行程Z axis tr***el | mm | 500 |
工作台承重table load | kg | 400 |
T型槽(数量-宽度-间隙)T slot(number-width-pitch) | 3-18x125 | |
主轴转速Max.Spindlespeed | rpm | 8000(Optional:10000) |
主轴锥度Spindle taper | mm | BT40 |
主电机功率Mainmotor power | kW | 5.5 |
X/Y/Z轴快移速度X/Y/Z rapid tr***erse speed | m/min | 24/24/20(Optional:48/48/36) |
切削进给速度Cutting feed speed | mm/min | 1-10000 |
导轨形式Guiderailtype | 线轨Linear rail | |
主轴中心到立柱表面距离 Distance from spindle axis to column surface | mm | 469 |
主轴端部到工作台表面距离 Distance between spindle nose and worktable surface | mm | 100-600 |
***精度Positioning accuracy | mm | ±0.0075 |
重复***精度Repeatpositioningaccuracy | mm | ±0.005 |
刀库Tool magazine | 斗笠Armless16(Optional:圆盘Arm 24) | |
刀具直径ol diameter | mm | Φ90 |
刀具重量ol weight | kg | 8 |
机床重量Machine weight | kg | 4000 |
外形尺寸Overall dimension | mm | 2400x2000x2550 |
