主要技术参数 | SPECIFICATI*** | Units | CK6160 |
床身上大回转直径 | Swing over bed | mm | 600 |
横滑板上大回转直径 | Swing over cross slide | mm | 280 |
大工件长度 | Distance between centers | mm | 750/1000/1500/2000/3000 |
主轴孔径范围 | Spindle bore | mm | 52,(80 for B),[105 for C] |
主轴孔径锥度 | Spindle bore taper | - | MT6,(φ90 1:20 for B),[φ113 1:20 for C] |
主轴鼻端型号 | Spindle nose type | - | C6,(D8 for B),[D8 for C] |
主轴转速级数 | Spindle speed steps | - | 手动3档Manual 3 steps (选配Optional: stepless) |
主轴转速范围 | Spindle speed range | rpm | 21-150,66-500,162-1500 (选配Optional: 100-1600 ) |
刀架类型 | Turret/tool post | - | 4工位电动刀架 Eletric 4 position |
刀具尺寸 | Tool size | mm | 25 x 25 |
X轴行程 | X axis tr***el | mm | 250 |
Z轴行程 | Z axis tr***el | mm | 750/1000/1500/2000/3000 |
X轴快速进给速度 | X axis rapid tr***erse | mm/min | 6000 |
Z轴快速进给速度 | Z axis rapid tr***erse | mm/min | 10000 |
尾座套筒直径 | Tailstock quill diameter | mm | 75 |
尾座套筒锥度 | Tailstock quill taper | - | MT5 |
尾座套筒行程 | Tailstock quill tr***el | mm | 150 |
主轴电机 | Main spindle motor | kw | 7.5 |
冷却泵电机 | Coolant pump motor | kw | 0.125 |
机床重量 Machine weight | Weightfor 750 | kg | 2500 |
Weightfor 1000 | kg | 2600 | |
Weightfor 1500 | kg | 2700 | |
Weightfor 2000 | kg | 3150 | |
Weightfor 3000 | kg | 3950 | |
外形尺寸 Overall dimension | Dimension for 750 | mm | 2550x1650x1750 |
Dimension for 1000 | mm | 2750x1650x1750 | |
Dimension for 1500 | mm | 3250x1650x1750 | |
Dimension for 2000 | mm | 3700x1650x1750 | |
Dimension for 3000 | mm | 4710x1650x1750 |
