主要技术参数 | SPECIFICATI*** | Units | CK6180E |
手动换挡Manual | |||
床身上回转直径 | Swing over bed | mm | 800 |
横滑板上回转直径 | Swing over cross slide | mm | 520 |
距 | Distance between centers | mm | 1000/1500/2000/3000/4000/5000/6000 |
床身导轨宽度 | Guideway width | mm | 550 |
床身承重范围 | Max. load capacity | T | 3 |
主轴孔径范围 | Spindle bore | mm | 104 |
主轴孔径锥度 | Spindle bore taper | - | Metric φ120/MT5 |
主轴鼻端型号 | Spindle nose type | - | C11 |
主轴转速级数 | Spindle speed steps | - | 3档变频 VF. 3 steps |
主轴转速范围 | Spindle speed range | rpm | 10-1000 |
卡盘规格 | Chuck | mm | φ315手动三爪 φ315 3-jaw manual |
刀架类型 | Turret/tool post | - | 4工位电动刀架 Eletric 4 position |
刀具尺寸 | Tool size | mm | 32×32 |
X轴行程 | X axis tr***el | mm | 420 |
Z轴行程 | Z axis tr***el | mm | 850/1350/1850/2850/3850/4850/5850 |
X轴快速进给速度 | X axis rapid tr***erse | mm/min | 4000 |
Z轴快速进给速度 | Z axis rapid tr***erse | mm/min | 6000 |
尾座套筒直径 | Tailstock quill diameter | mm | φ100 |
尾座套筒锥度 | Tailstock quill taper | - | MT5 |
尾座套筒行程 | Tailstock quill tr***el | mm | 250 |
主轴电机 | Main spindle motor | kw | 11 |
冷却泵电机 | Coolant pump motor | kw | 0.125 |
机床重量 Machine weight | Weight for 1000 | kg | 3900 |
Weight for 1500 | kg | 4300 | |
Weight for 2000 | kg | 4700 | |
Weight for 3000 | kg | 5500 | |
Weight for 4000 | kg | 6300 | |
Weight for 5000 | kg | 7100 | |
Weight for 6000 | kg | 7900 | |
外形尺寸 Overall dimension | Dimension for 1000 | mm | 3300x1850 x1900 |
Dimension for 1500 | mm | 3800x1850 x1900 | |
Dimension for 2000 | mm | 4300x1850 x1900 | |
Dimension for 3000 | mm | 5300x1850 x1900 | |
Dimension for 4000 | mm | 6300x1850 x1900 | |
Dimension for 5000 | mm | 7300x1850 x1900 | |
Dimension for 6000 | mm | 8300x1850 x1900 |
