| 品牌 | 绿洲 | 型号 | XBSL-19（3/4） |
| 别名 | 实验立式砂泵 | 用途 | 实验室输送矿浆 |
| 生产能力 | 00 | ***大进料粒度 | 00 |
| 出料粒度 | 00 | 给料口尺寸 | 13mm |
| 重量 | 110kg | 电动机转速 | 00 |
| 电动机功率 | 00 | 产品别名 | 实验立式砂泵箱 |
| 外形尺寸 | 480/350/550 | 输出功率 | 0.75 |
石城县绿洲选矿设备生产
试验立式砂泵技术参数
Technical Parameter of laboratory Vertical Sand Pump
XBSL型立式砂泵用于实验室输送矿浆和牌位矿，也可用于选煤厂输送介质，铝厂输送高温易结晶的料将以及水泥厂输送料等。本产品由原地矿部***指定企业生产，执行行业标准。
XBSL type vertical sand pump for conveying the pulp and tablets of mine laboratories can also be used in coal preparation plant tran***ission medium, aluminum easy to transport high-temperature crystallization, as well as cement plants are expected to transport materials.This product is the only designated former Ministry of Geology and Mineral production, the implementation of industry standa***.
型号Model | 单位 Uite | XBSL13(1/2) | XBSL19(3/4) | XBSL25(1) | XBSL38(3/2) |
排矿口直径Outler diameter | mm | 13 | 19 | 25 | 38 |
扬程Head | m | 5 | 6 | 9 | 12 |
流量Flow rate | L/min
| 20-30 | 55 | 110 | 250 |
给矿浓度Feed density | % | 30 | 30 | 30 | 30 |
电压Voltage | v | 380 | 380 | 380 | 380 |
功率power | kw | 0.75 | 1.1 | 1.5 | 3 |
外形Overall dimensi*** | mm | 420/280/460 | 480/350/550 | 680/500/640 | 690/480/680 |
重量Weighe | kg | 65 | 110 | 157 | 200 |
