类型 | 见详参 | 品牌 | 台湾三华 |
型号 | 有源差分探头SI200 | 测量范围 | 见详参(V) |
重量 | 300(g) | 外形尺寸 | 111*22*14(mm) |
电压测量误差 | &plu***n;1% |
Specificati*** | |
Bandwidth | 200MHz |
Attenuation | 1/10 |
Accuracy | &plu***n;1% |
Input Impedance | 500KΩ//7 p F each side ground |
Input Voltage | |
-Differential Input Voltage | &plu***n;20V |
-Common Mode Voltage | &plu***n;60V |
-Absolute Max.Voltage (either input to ground) | &plu***n;60V |
Output Voltage | |
-Swing(into 50 KΩ load) | &plu***n;2V |
-Offset(typical) | <&plu***n;2mV |
-Source Impedance(typical) | 50Ω |
CMRR(typical) | -80 d B @100Hz;-50db@10MHz |
Power Requirements | |
-Standard | 6V DC/90m A or 9V DC/70m A mains adaptor |
-Opti*** | Removable battery pack or power leads |
Length of BNC Lead | 125cm |
Length of Input Leads | 50cm |
Weighr | 300g |
Dimension(L×W×H) | 111mm×22mm×14mm |
Features: Bandwidth up to200MHz 0.1m V Sensitivity | |
Applicati***: Telecom Measurement x DSL Applicati*** High Speed Power Measurement Differential Line Tran***itter and Receiver Design |
