带旋转手柄的菱形切割滚花旋钮MBT+I

MBT+I

Diamond cut knurled knobs

with side handle

•High impact
strength polypropylene based (PP)

technopolymer.

Resistant to solvents, oils, greases and other chemical
agents.

•Blackstandard
colour with matte finish.

•Brass insertwith
plain blind hole.

•Technopolymer
revolving handleI.701+x.
(page 267).

•Complete with
socket set screwfor fitting to shaft in accordance with

UNI 5929-85 (grub screw with hexagonal socket and cup
end).

The outside rim has been designed with a truncated
diamond knurl that

provides a comfortable grip. The special technopolymer
and the ***ooth

knurled structure of relatively fine pitch offered with
this knob, enable the short

angular adjustments and a comfortable grip in working
conditi***.

The revolving handle simplifies the rapid rotation of the
knobs.

带旋转手柄的菱形切割滚花旋钮

材料：

高弹性聚丙烯基(pp)高科技聚合体。耐溶剂、机油、油脂以及其它化学溶剂。

颜色：

黑色，亚光饰面

旋转手柄：

I．170+X型聚酰胺基（PA）高科技聚合体旋转手柄，黑色，亚光饰面。

装配：

铜毂，盲光孔。提供符合UNI5929-85（埋头螺钉带螺丝刀开槽头及杯状端）要求的，用于装配到轴上的***螺钉。供货已装配。

***工程学及设计概念

旋钮外缘的菱形切割花的间距很小，便于安全、舒适地紧握、从而使操作者在微距调整的过程中仍可进行灵敏操作。旋转手柄简化了旋钮的快速旋转操作，特别使用于要去多次连续旋转的场合。
