POLT THREE-PHASE CYLINDRICAL CAPACITOR西班牙LIFASA电容器

International Capacitors S.A. is a Spanish company located near Barcelona, specializing in manufacturing electrical capacitors under the LIFASA trademark.

Production program includes:

·Lighting Capacitors
·Motor Run Capacitors
·Power Electronic Capacitors
·Reactive Power Compensation:
    Power capacitors
    Controllers
    Automatic capacitors banks
    Harmonic filters
·Network Analyzers
·High Voltage Capacitors

■     Lifasa capacitors are present in the market since 1949.More than 50% are exported to 70 countries in five continents.

■      International Capacitors is a Registered Firm By BSI.The quality system complies with ISO 9000 standard and has been successfully audited by BSI since 1986.

■      The company is committed to give the best SERVICE with maximum FLEXIBILITY to meet customer requirements. Every person in the company is trained and encouraged to participate actively in achieving this objective.

■      The company has implemented an Environmental management System according to EU Eco-management and Auditing Scheme and ISO 14000 standard.

■      LIFASA capacitors are manufactured according to European and other International Standards. They have obtained large number of certificates and approvals.

■      Products shown here carry the CE mark as they match Electro Magnetic Compatibility and Low Voltage Directives.

    From our beginnings, our will and dedication has made the capacitor, in anyone of its applications, our vocation.

    The evolution from the first lighting capacitors to the units of high voltage and a resolved bet for the variable speed drives, it has had and has a clear objective, the contribution of LIFASA to the energy saving by means of the administration of the electric loads.

    Also, the biggest complexity in the industrial networks has taken to the position of the quality of the wave like a high-priority objective.

    The combination of experience, knowledge and service make that our offer is the perfect solution whatever is your necessity.
原FMD系列产品现已升级换代为FML系列，新产品增加60%使用寿命；同一产品适用于不同电压等级，为客户提供更多便利；产品尺寸与原来相同，便于用户替换原使用产品，重量比原来产品有大幅下降；产品颜色由原来的蓝色改变为灰白色（RAL7035）。详细产品资料请参见产品介绍或来信来电咨询。



    西班牙LIFASA公司自1949年起生产高品质电容等产品，在高级酒店和大厦用电容领域占据绝对优势，超过50%的产品出口到其他世界各地，产品畅销五大洲七十多个国家。产品质量符合ISO 9000标准。产品包括：马达启动电容、高压电力电容器、照明电容器、电容器组、附接触器无功补偿电容、滤波阻抗电容、铝电解电容器、高频旁路电容器、高频耦合电容器、陶瓷电容器、调谐电容器、聚苯乙烯电容器、塑料薄膜电容器、吸收过滤器…
    西班牙LIFASA产品符合国际电工委员会推荐标准IEC831-1及IEC831-2《额定电压660V及以下交流系统用自愈式并联电力电容器》。 LIFASA电容器系适用于工频50Hz或60Hz、额定电压1000V及以下的交流电力系统中与负载并联，以提高系统的功率因数。该电容器以金属化聚丙烯薄膜作电极和介质，因而产品具有自愈性能，并同时具有重量轻、体积小、损耗低等优点。而且电容器内部装有过压力保护装置、过电流保护器和放电电阻，有很高的可靠性和安全性。 西班牙LIFASA电容器采用独特设计的自愈式金属化薄膜，大大增强了电容器元件的端面接合力和高耐压的要求，从而提高了电容器的抗涌流性能和可靠性；减少了投入电容器瞬间对元件的电流冲击，从而有效延长电容器的使用寿命。
    上海山合海融商贸有限公司代理销售西班牙LIFASA公司电容器类产品，主要包括以下部分型号，具体产品规格及价格请来电、来信联系：
    AMIFA2066025、PECA10630100A、PARM25100P、P9425020P、LUX-FP 25120A、N750、BATM034005、BATN1223022、BATS4840480、BATN2440160、BATN4540450、BATN7540600、MOD8440100、BATS1040087、BATS2040200、BATS4840480、INA40997、FMF4698、INR40807、BATF3240320、BATSF4840250、MCS50、MCX73、TCP81212505、SOFTMCA、MCA01480、POLIMET、MINIFIMETAL、POLB23033、MFB40100、FML4440（原FMD4030）、FML4460（原FMD4050）、FMY6680、FMY6999、FMC0070、FMZ2250、FMH2310、FMT2320、CPM4020、CPF4075、CAB04015、FMR4040、ELEFP40025A等等。
产品描述：
1． 螺栓出线方式，保证了接线的可靠稳定，满足大容量、大电流的要求；
2． 安全可靠的美式过压力防爆结构，内置式放电电阻，使得产品更安全，更可靠；
3． 长寿命、多元件设计，增加散热面积，使电容器的温升更低，延长电容器的使用寿命，平均寿命达到100,000小时；
4． 电容器元件用金属化薄膜采用特别的方阻设计，既有很高的自愈性能，又满足了高可靠性的接触和高耐压的要求；
5． 安全有效的防护措施，免除对人体的伤害；
6． 方便可靠的安装方式，提高了工作效率；
7． 优质圆柱形铝外壳，美观漂亮，更小的体积，使得单柜的容量更大。工业产品的设计家电化，提升成品形象，为客户创造最大价值。
8． 产品符合IEC831-1，IEC831-2国际标准和GB/T12747-2004国家标准的要求。

Polimet Power Capacitors

Description Self-healing capacitors with low loss metallized polypropylene dielectric. Capacitors mounted in cylindrical aluminium cans with M12 stud for fixing and earthing and fitted internally with discharge resistors. Connection is made through Faston terminals (POLT version) or by block terminal (POLB version). These capacitors are specially suitable for the individual compensation of small inductive loads. Technical Characteristics Frequency 50 Hz Dielectric Polypropylene Discharge resistors Fitted Dielectric losses ＜ 0.2 W/kvar Total losses ＜ 0.4 W/kvar Max. overvoltage 1.1U N Max. overcurrent 1.3I N Power tolerance -5/+10% Temperature range -40/+ 50 ℃ Insulation level 3/-kV Connection terminal Terminal block(POLB version) Double Faston 6.35(POLT version) Maximum torque for stud 12 N.m Standards IEC 831-1, IEC 70/ 70A , BS 1650, VDE 560, En 60831 *Other voltages and frequencies on request.
