FTB8010HW-PT脉冲输出流量计 美国omega
显示累加流量和流速的热水仪表，可提供脉冲输出
FTB8000HW Series
显示累加流量和流速的热水仪表，可提供脉冲输出
Flow Rates from 0.22 to 132 GPM
150 psi Maximum Operating Pressure
90°C (194°F) Maximum Operating Temperature
Field-Adjustable Pulse Output (Optional)
The FTB8000HW Series meters use the multi-jet principle, which has been an internationally accepted standard for many years. This type of meter is known for its wide range, simplicity, and accuracy in lowquality water. The impeller is centered in a ring of jets, with inlet jets on one level and outlet jets on another. A gear train drives the register totalizer dials. For pulse output, one of the dials is replaced by a gear, which turns a magnet that is detected by an encapsulated sensor threaded into the outside of the lens. Pulse rate is determined by the gear and the dial on which the gear is placed. Changing the pulse rate requires no special tools and can be done in the field.
Mechanically, all FTB8000HW meters are the same. The difference between the -PR, -PT, and standard models is in the sensor. -PR model meters use a solid state, longlasting Hall-effect sensor, which requires power. -PT model meters use a 2-wire reed switch. They provide a dry-contact closure and do not require power. Basic FTB8000HW meters totalize only and do not h***e an output. Never install water meters above or over areas where leakage would cause damage.
SPECIFICATI***
Materials:
Body: Cast bronze
Internals: Engineered thermoplastic
Magnet: Permanent ceramic
Max Temperature: 90°C (194°F)
Max Operating Pressure: 150 psi
Accuracy: 1.5% of reading
Sensor:
-PR: Hall-effect device
-PT: Reed switch
Max Current: 20 mA
Max Voltage:
-PR: 24 Vdc
-PT: 24 Vdc or Vac
Sensor Power (-PR): Minimum 6 mA at 12 Vdc
Cable Length: 4 m (12') standard, 600 m (2000') max
Flow Rates (GPM):
NPT Size ? 1 1? 2
Minimum 0.22 0.44 0.88 1.98
Maximum 22 52 88 132
产品型号/产品描述
FTB8007HW 3/4NPT, 0.22 to 22 GPM, total only
FTB8010HW 1NPT, 0.44 to 52 GPM, total only
FTB8015HW 1 1/2NPT, 0.88 to 88 GPM, total only
FTB8020HW 2NPT, 1.98 to 132 GPM, total only
FTB8007HW-PT 3/4NPT, 0.22 to 22 GPM, 20 Pulse/gallon
FTB8010HW-PT 1NPT, 0.44 to 52 GPM, 1 Pulse/gallon
FTB8015HW-PT 1 1/2NPT, 0.88 to 88 GPM, 1 Pulse/gallon
FTB8020HW-PT 2NPT, 1.98 to 132 GPM, 1 Pulse/gallon
FTB8007HW-PR 3/4NPT, 0.22 to 22 GPM, 1 Pulse/gallon
FTB8010HW-PR 1NPT, 0.44 to 52 GPM, 1 Pulse/gallon
FTB8015HW-PR 1 1/2NPT, 0.88 to 88 GPM, 1 Pulse/gallon
FTB8020HW-PR 2NPT, 1.98 to 132 GPM, 1 Pulse/gallon
注释: Comes with 2 MNPT couplings (already installed), 4m (12') cable, and complete operator’s manual.
