HHF801叶轮风速计 美国omega
经济型叶轮风速计
HHF801
经济型叶轮风速计
13毫米直径的重型迷你叶片
望远镜的功能，600毫米（23.6“）
超大的液晶读空气流速和温度同时
记录***小和***大读数与召回
数据保持功能
自动关机
RS232串行接口
这是任何空气流动hhf801应用，例如风速计经济的解决方案，空调和供暖系统，风的速度，平衡，和环境测试。便携式hhf801提供快速，数字的可读性和远程探头方便准确的读数。结合叶片和标准热敏电阻提供快速和***的测量。微处理器电路保证***大可能的精度和提供特殊的功能和特点。
| Measurement | Range | Resolution | Accuracy |
|---|---|---|---|
| m/s | 0.8 to 12.0 m/s | 0.1 m/s | &plu***n;(2% + 0.2 m/s) |
| km/hr | 2.8 to 43.3 km/hr | 0.1 km/hr | &plu***n;(2% + 0.2 km/hr) |
| ft/min | 160 to 2358 ft/min | 1 ft/min | &plu***n;(2% + 20 ft/min) |
| mile/hr | 1.8 to 26.8 mph | 0.1 mph | &plu***n;(2% + 0.2 mile/hr) |
| knots | 0.8 to 23.3 knots | 0.1 knots | &plu***n;(2% + 0.2 knot) |
| Temp (°C) | 0 to 80°C | 0.1°C | &plu***n;0.8°C |
| Temp (°F) | 32 to 176°F | 0.1°F | &plu***n;1.5°F |
规格：
Display: 51 x 32 mm (2 x 1.25") LCD
Measurement: m/s, km/h, ft/min, knots, miles/h, Temperature in °C or °F, and Data Hold
Sensor Structure:
Air Velocity: Vane with low friction ball bearing design
Temperature: Precision thermistor
Memory: Minimum and Maximum with Recall
Power Off: Auto shut off or manual button
Sampling Time: 0.8 seconds
Data Output: RS232
Operating Temperature: 0 to 50°C (32 to 122°F)
Operating Humidity: <80% RH
Power Supply: one 9 Vdc he***y duty battery (included)
Power Current: Approx. 8.3 mA dc
Overload Indication: “----”
Dimensi***:
Instrument: 200 x 68 x 30 mm (7.9 x 2.7 x 1.2")
Telescope Probe: 13 dia x 280 mm L (0.5 x 11") (min. length) to 600 mm (23.6") (max length)
Weight: Approx 220 g (0.5 lb)
产品型号/产品描述
HHF801 经济型叶轮风速计
Accessories
HHF801-PROBE Replacement vane
SWCABLE Software and cable
MN1604 Replacement 9 V battery
注释: Comes complete with operator’s manual, hard carrying case and 9 V battery.
