OTP蓄电池12V17AH OTP电池6FM-17 OOTP蓄电池12V17AH OTP电池6FM-17
OTP蓄电池12V17AH OTP电池6FM-17 OOTP蓄电池12V17AH OTP电池6FM-17
| 品牌 | OTP | 型号 | 6FM-17 | 化学类型 | 铅酸蓄电池 |
| 电压 | 12（V） | 类型 | 固定型蓄电池 | 荷电状态 | 免维护蓄电池 |
| 电池盖和排气拴结构 | 阀控式密闭蓄电池 |
规格参数
型号额定
电压
(V)10HR
1.80V/C5HR
1.75V/C1HR
1.75V/C长(mm)宽(mm)高(mm)总高(mm)参考
重量
(kg)端子
类型端子
布局内阻
(mΩ)
| 6FM-7 | 12 | 6.5 | 5.6 | 4.2 | 151.0 | 65.0 | 94.0 | 100.0 | 2.50 | F1 | b | 26 |
| 6FM-17 | 12 | 15.8 | 13.6 | 10.2 | 181.0 | 77.0 | 167.0 | 167.0 | 5.75 | M5 | d | 14 |
| 6FM-24 | 12 | 24.0 | 19.2 | 14.4 | 166.0 | 126.0 | 174.0 | 174.0 | 8.90 | M6 | d | 12 |
| 6FM-38 | 12 | 38.0 | 30.4 | 22.8 | 198.0 | 166.0 | 175.0 | 175.0 | 13.5 | M6 | d | 8 |
| 6FM-65 | 12 | 65.0 | 52.0 | 39.0 | 330.0 | 173.0 | 171.0 | 176.0 | 22.6 | M8 | c | 7.5 |
| 6FM-100 | 12 | 100.0 | 80.0 | 60.0 | 329.0 | 172.0 | 217.0 | 222.0 | 29.0 | M8 | c | 5 |
| 6FM-120 | 12 | 120.0 | 96.0 | 72.0 | 409.0 | 177.0 | 225.0 | 225.0 | 35.0 | M8 | c | 4 |
| 6FM-150 | 12 | 150.0 | 120.0 | 90.0 | 532.0 | 207.0 | 214.0 | 219.0 | 48.5 | M8 | a | 3.5 |
| 6FM-200 | 12 | 200.0 | 160.0 | 120.0 | 523.0 | 240.0 | 225.0 | 230.0 | 58.5 | M8 | a | 3 |
| 6FM-240 | 12 | 220.0 | 204.0 | 144.0 | 520.0 | 269.0 | 204.0 | 208.0 | 70.2 | M8 | a | 2.2 |
| 6FM-280 | 12 | 255.0 | 238.0 | 168.0 | 521.0 | 269.0 | 220.0 | 224.0 | 76.0 | M8 | a | 1.8 |
型号额定容量10小时率Ah标称
电压
(V)长(mm)宽(mm)高(mm)总高（含端子）(mm)参考
重量
(kg)内阻
(mΩ)端子类型
| GFM-100 | 100 | 2 | 171 | 72 | 205 | 229 | 6.0 | 1.1 | M8 |
| GFM-200 | 200 | 2 | 172 | 111 | 329 | 365 | 12.9 | 0.9 | M8 |
| GFM-300 | 300 | 2 | 171 | 151 | 330 | 366 | 17.7 | 0.5 | M8 |
| GFM-400 | 400 | 2 | 210 | 171 | 329 | 363 | 24.7 | 0.5 | M8 |
| GFM-500 | 500 | 2 | 241 | 172 | 331 | 366 | 29 | 0.55 | M8 |
| GFM-600 | 600 | 2 | 301 | 175 | 331 | 366 | 34.6 | 0.5 | M8 |
| GFM-800 | 800 | 2 | 410 | 176 | 330 | 365 | 49 | 0.24 | M8 |
| GFM-1000 | 1000 | 2 | 475 | 175 | 328 | 365 | 56.3 | 0.2 | M8 |
| GFM-1500 | 1500 | 2 | 401 | 351 | 342 | 378 | 93 | 0.2 | M8 |
| GFM-2000 | 2000 | 2 | 491 | 351 | 343 | 383 | 123 | 0.12 | M8 |
| GFM-3000 | 3000 | 2 | 712 | 353 | 341 | 382 | 182 | 0.11 | M8 |
