INFUSE? 9507
Olefin Block Copolymer
The Dow Chemical Company
产品说明：
INFUSE? 9507 Olefin Block Copolymer is a high performance olefin block copolymer that has excellent flow characteristics and performs well in a wide range of general purpose thermoplastic elastomer applicati***, such as injection molding and profile extrusion.
INFUSE 9507 provides outstanding haptics in over molding applicati*** with polypropylene (PP) and Polyethylene (PE). In addition its lower density can help control resin and production costs, while reducing the weight of end products.
Main Characteristics:
High upper service temperature performance
Highly flexible with good elastic recovery
Fast set up times for processability
General purpose elastomer
Excellent for compounds and blends
Talc dusted
Complies with
EU, No 10/2011
U.S. FDA FCN 424
C***ult the regulati*** for complete details
INFUSE? 9507 物性表
| 基本信息 | |
|---|---|
| 机构评级 |
|
| 形式 |
|
| 物理性能 | 额定值 | 单位制 | 测试方法 |
|---|---|---|---|
| 比重 | 0.866 | g/cm3 | ASTM D792 |
| 熔流率（熔体流动速率）(190°C/2.16 kg) | 5.0 | g/10 min | ASTM D1238 |
| 硬度 | 额定值 | 单位制 | 测试方法 |
|---|---|---|---|
| 肖氏硬度(邵氏 A, 模压成型) | 60 | ASTM D2240 |
| 机械性能 | 额定值 | 单位制 | 测试方法 |
|---|---|---|---|
| 拉伸模量 - 100% 正割(模压成型) | 1.49 | MPa | ASTM D638 |
| 抗张强度(断裂, 模压成型) | 2.89 | MPa | ASTM D638 |
| 伸长率(断裂, 模压成型) | 1200 | % | ASTM D638 |
| 弹性体 | 额定值 | 单位制 | 测试方法 |
|---|---|---|---|
| 抗张强度(断裂) | 7.00 | MPa | ASTM D412 |
| 伸长率(断裂) | 1900 | % | ASTM D412 |
| 撕裂强度 | 22.0 | kN/m | ASTM D624 |
| 压缩*变形 | ASTM D395 | ||
| 21°C | 22 | % | ASTM D395 |
| 70°C | 70 | % | ASTM D395 |
| 热性能 | 额定值 | 单位制 | 测试方法 |
|---|---|---|---|
| 溶融温度（DSC） | 119 | °C | 内部方法 |
| TMA1(1.00 mm) | 77 | °C | 内部方法 |
| 备注 | |
|---|---|
| 1 . | 1N，5°C/分 |
