YAMAHA飞达/YAMAHA飞达大连杆/YAMAHA飞达配件
K87-M1320-10X 导带齿轮 CL8X2 SPROCKET
KW1-M1113-000 8mm***柱 Knock pin(Front/ Rear)
KW1-M111T-00X 螺丝 SCREW
KW1-M1191-001 单向轴承卷带轮 DRIVE ROLLER UNIT
KW1-M1192-00X CL8mm 单向轴承 INDENTATION LVR ASSY
KW1-M119F-00X CL8mm 大卷带轮 DRIVE ROLLER ASSY
KW1-M119L-00X 带轴承小卷带轮 IDLE ROLLER ASSY
KW1-M11A1-011 单向轮底部导向片 Lower Guide Plate
KW1-M11D0-200 FEEDER 尾巴 REEL HOLDER ASSY
KW1-M1340-00X 老款压料盖 CL8X2 TAPE GUIDE
KW1-M1340-010 CL8x2,NEW压料盖 Tape Guide Unit
KW1-M134T-00X 弹片及螺丝 LEAF SPRING & SCREW
KW1-M1540-00X CL823压料盖 Tape Guide Assy
KW1-M119K-00X CL8mm弹簧 SPRING
K87-M112D-10X
KW1-M111E-00X 推动鸟咀弹簧
KW1-M111A-00X 止动鸟咀弹簧
KW1-M119K-00X 大单向轮拉力弹簧
KW1-M119P-00X 小单向轮压力弹簧、AMAHA FEEDER12 16mmPARTS LIST
K87-M1112-100 12/16mm***柱 Knock pin
K87-M212L-10X 导带齿轮轴 Sprocket Axis Assy (CL12/16)
KW1-M125L-100 手柄 HOLD ARM (CL12/16mm)
KW1-M222A-00X 导带齿轮推动片 Racking Lever Assy (CL12&16)
KW1-M2231-001 前固定扣 Clamp Lever Unit (CL12/16mm
Tape Guide Plate Unit CL12/CL16压料盖 Tape Guide Plate Unit
KW1-M224A-00X 连杆组合 HAND LEVER ASSY (CL12mm)
KW1-M224D-00X 后连杆 SUB ARM (CL12mm)
KW1-M2250-000 手柄杆 Handle Lever Assy (CL12mm
KW1-M226D-00X 小卷带轮杆及配件 TENSION LEVER ASSY (CL12/16)
KW1-M2277-00X 前连杆 MAIN ARM (CL12mm)
KW1-M2285-00X CL12/16mm) 气缸 MULTI CYLINDER
KW1-M2291-000 带单向轴承卷带轮 DRIVE ROLLER UNIT (CL12/16)
KW1-M2292-00X 单向轴承 INDENTATION LVR ASSY (CL12mm
KW1-M229F-000 大卷带轮 DRIVE ROLLER ASSY (CL12mm
KW1-M229L-000 带轴承小卷带轮 IDLE ROLLER ASSY (CL12mm)
KW1-M324A-000 手连杆 HAND LEVER ASSY
KW1-M329F-00X CL16mm) 大卷带轮 DRIVE ROLLER ASSY
KW1-M329L-000 带轴承小卷带轮 IDLE ROLLER ASSY (CL16mm)
YAMAHA FEEDER 24-72mm PARTS LIST KW1-M4500-015 FEEDER CL24mm
K87-M2131-001 前固定扣 Clamp Lever Unit (CL24~72mm)
K87-M2381-000 气缸 AIR CYLINDER (CL24~72mm)
KW1-M451D-001 弹簧 SPRING (CL24~72mm)
K87-M559A-000 齿轮 DRIVE GEAR ASSY
K87-M559K-000 齿轮 INDEX GEAR
KW1-M4512-000 ***柱 Knock Pin (CL24~72mm)
KW1-M451G-000 连接片 LEVER ASSY
KW1-M451H-000 铁鸟嘴 BACK STOPPER (CL24~72mm)
KW1-M4520-000 导带齿轮 SPROCKET ASSY (CL24~72mm)
KW1-M452A-000 齿轮推动片 Racking Lever Assy (CL24~72mm)
KW1-M4540-000 压料盖 Tape Guide Assy (CL24mm-72mm)
KW1-M4540-010 新款压料盖 Tape guide unit (CL24~56mm)
KW1-M454A-020 压盖锁扣 LOCK LEVER ASSY (CL24~72mm)
KW1-M456N-000 料盘固定盖 Reel Cover Assy (CL24~72mm)
KW1-M4577-000 前连杆 MAIN ARM (CL24~72mm)
KW1-M458A-001 设置盘组合装置 SET PLATE ASSY (CL24~72mm
KW1-M459L-000 后连杆 SUB ARM (CL24~72mm)
KW1-M459N-000 卷带轮 ROOL UP Assy (CL24~72mm)
KW1-M459U-000 卷带轮盖 Reel Plate
