***代理西门子X系列贴片机
SIPLACE西门子贴片机X系列的技术参数
|
机器特性 |
SIPLACE X4i S |
SIPLACE X4 S |
SIPLACE X3 S |
|
悬臂数量 |
4 |
4 |
3 |
|
贴装性能 |
|
|
|
|
IPC速度 |
102,000 cph |
85,000 cph |
64,983 cph |
|
SIPLACE基准评测 |
120,000 cph |
100,000 cph |
76,450 cph |
|
理论速度 |
135,500 cph |
112,500 cph |
86,006 cph |
|
机器尺寸 |
|
|
|
|
|
1.9 x 2.3* |
1.9 x 2.3* |
1.9 x 2.3* |
|
贴装头特性 |
SpeedStar |
MultiStar |
TwinStar |
|
元器件范围 |
03015 - 6 x 6 mm |
03015 - 50 x 40 mm |
0201" - 200 x 125 mm |
|
贴装准确性 |
&plu***n; 41 μm/3σ |
&plu***n; 41 μm/3σ (C&P) |
&plu***n; 22 μm/3σ |
|
|
|
&plu***n; 34 μm/3σ (P&P) |
|
|
角精度 |
&plu***n; 0,5°/3σ |
&plu***n; 0,4°/3σ (C&P) |
&plu***n; 0,05°/3σ |
|
|
|
&plu***n; 0,2°/3σ (P&P) |
|
|
传送带特性 |
|
|
|
|
传送带类型 |
Single Transport, Flexible Dual Transport |
||
|
传送带模式 |
Asynchronous, synchronous, i-placement (X4i S) |
||
|
PCB格式 |
50 x 50 mm2 to 650 x 560 mm2 max. (X4 S, X3 S) ** |
||
|
|
50 x 50 mm2 to 610 x 560 mm2 max. (X4i S) |
||
|
PCB厚度 |
0,3 to 4,5 mm (other thicknesses upon request) |
||
|
PCB重量 |
3 kg max. |
||
|
元器件供应与供料 |
|
|
|
|
供料器位置 |
X3 S & X4 S: 160 tracks with 8 mm X-feeders |
||
|
|
X4i S: 148 tracks with 8 mm X-feeders |
||
|
元器件供应 |
SIPLACE component cart, SIPLACE Matrix Tray Changer (MTC) (3S & X4S), JTF2 + JTF3 (X3 S, X4 S, X4i S) |
||
|
|
SIPLACE X-feeders |
||
|
|
Tray, stick magazine, bulk case, application-specific OEM feeder modules |
||
|
质量评级 |
|
|
|
|
拾取率 |
≥ 99,95%*** |
|
|
|
DPM速率 |
≤ 3 dpm*** |
|
|
|
照明等级 |
up to 6 |
||
